ACO 3116 - RS-232 C Communication Setup

― 31 ―
Handling of an option article
Set up of RS-232C
Set up the RS-232C by
Menu 3/3 baud rate
of a main body.
1）It is made a screen.
<Menu 3/3>
with push 3 times
Menu
.
Cursor button 4 direction
Menu Save/Set
2) Select
baud rate
with Cursor button , then move the cursor rightward with cursor
button .
<Menu> 3/3
Moni/Level :AC
AutoPwrOff :OFF
LCD cont :*
baud rate :9600
3) Set the 9600 with cursor button , then press
Save/Set
button to save the setting.
