― 10 ―
Names and functions of various parts
Accelerometer
Curl Cable
BNC Connector
BNC Connector
Connect to Input Terminal of Main Body TYPE 3116
！ CATUION
● The connection connector of a main body and a curl cable is an one-touch type BNC
connector. Please do not turn by the connector part the time of connection, or after
connection. It becomes the cause of failure or incorrect operation.
Type F connector
Connect to Output Terminal of TYPE 7812B
Accelerometer TYPE 7812B
Detect vibration and change it into an electric signal and fix it with screw stoppers in
un-measurement.
(Reference to P. 18 ～P. 19 How to fix)
Accelerometer
TYPE 7812B
Type F Connector
To Next Page
