ACO 3116 - Connection of Pc and Type 3116

Data management software NA-0116
3
2. Connection of PC and TYPE 3116
1) When using BC-0026PC
To connect PC and Type 3116, use interface cable BC-0026PC as follows:
Interface connector
Interface cable BC-0026PC
PC
To RS-232C
2) When using BC-0026
To connect PC and Type 3116, use interface cable BC-0026 and conversion connector
A12-25F-9F (option) as follows:
Interface connector
Interface cable BC-0026
PC
To RS-232C
Conversion connector A12-25F-9F
