5. DEVICE AND AMPLIFIER SETTINGS
5.1. Device (eBox) Settings
When you use the eBox for a first time, the device is not configured to operate with a specific amplifier
model (factory setting). The first screen you will see is shown on Figure 4-1 eBox web-interface access. How to
select an amplifier model is described in Section 5.2 Amplifier Settings.
Once you are successfully logged-in, the Home and Settings menus will be shown in the menu bar of the
web-page. The ACOM eBox factory default settings (Administrator access level) are shown on Figure 5-1
eBox Settings
Device menu.
The settings screen is divided in panels in which the different parameters are thematically grouped.
a) Device Status panel
This panel (see Figure 5-1 eBox Settings
Device menu, Pos. (a)) displays the current firmware and library
versions, the serial number of the specific device, its physical network address (MAC address), the current
date and time as well as the total device uptime.
The panel is visible for both User and Administrator authentication levels.
If the eBox device does not have access to an Internet time-server (NTP server) the date
and time shown in Device Status
Device Time section may be incorrect, but this does
not affect the proper operation of the device.
b) Network Status panel
This panel (see Figure 5-1 eBox Settings
Device menu, Pos. (b)) displays the current settings for the IP
address, type of IP address (manually entered static address or DHCP assigned dynamic address), network
mask as well as primary and secondary DNS.
The panel is visible for both User and Administrator authentication levels.
