8. SPECIFICATIONS
8.1. Characteristics
a) Compatibility
Designed for remote access and control via a local network or over the Internet of the following ACOM
power amplifier models:
• ACOM 600S
• ACOM 700S
• ACOM 1200S and
• ACOM 2000A with its own RCU (Remote Control Unit);
b) Power supply adapter
• Input: 100-240 VAC / 1.0 A max.;
• Output: 12 VDC / 2.0 A;
• Output power: 24 W max.;
• Cable length: Approx. 1.5 m;
• Power input plug type: Europlug;
c) Connection cable (eBox - ACOM amplifier connection)
• Cable length: 1 m;
NOTICE
Be careful to use the correct connection cable between AMPLIFIER connector (on eBox
rear panel) and:
- ACOM 600S, 700S or 1200S amplifier RS-232 connector (on amplifier rear panel), or
- ACOM 2000A amplifier REMOTE CONTROL connector (on amplifier rear panel).
The connection cable must correspond to your amplifier model and should be specified
when you order the eBox.
Using an inappropriate cable may cause a serious damage to the eBox device and your
amplifier!
d) Connectors
• LAN - standard RJ-45 socket for Ethernet connection;
• AMPLIFIER - D-sub, 15-pin, male connector for connection to ACOM amplifier;
• RCU - D-sub, 9-pin, female connector for connection to RCU (Remote Control Unit));
• POWER - input power socket, 12 VDC / 2.0 A.
e) Size & Weight (operating, excluding cables and power supply adapter):
• WxDxH: 105x131x34 mm, 0.3 kg (4.2x5.2x1.4 inches, 0.7 lbs.);
