b) PA Settings panel
Please, see Figure 5-5 eBox with ACOM 2000A connected, Pos. (b).
Changes to this panel can be made only while the amplifier is switched OFF.
Panel functional buttons:
• Clear User Tunings
Clears the tunings done by the user;
• Revert
When it is pressed the change in the panel will go back to the last saved value;
• Save
When it is pressed the changes in a panel are saved.
Panel functional fields:
• Auto Operate
Enable/Disable Auto Operate feature. When Auto Operate is enabled the amplifier will
automatically revert to OPERATE mode after a soft-fault protection trip;
• RCU Local Control
Enable/Disable local control of the amplifier from its own RCU;
• Auto Ant. Change
Automatically select an antenna, corresponding to the measured frequency of the drive
signal. Requires an antenna to be set for the corresponding band (see Section 5.2.1.d) Antenna
Assignment panel);
• Self Address
When ACOM 2000A amplifier is part of serial network chain, you can assign amplifiers self-
address here. When the amplifier is not used in serial network chain, this address is
meaningless.
c) Antenna Alias panel
Please, see Figure 5-5 eBox with ACOM 2000A connected, Pos. (c).
Panel functional buttons:
• Revert
When it is pressed the change in the panel will go back to the last saved value;
• Save
When it is pressed the changes in a panel are saved.
Panel functional fields:
• Antenna 1, 2, … 10
Assign names of the used antennas (max. 10 antennas). This feature is used when working
together with an automatic antenna selector ACOM 2000S and remote antenna switch ACOM
2000SW.
