ACTsmart2 Operating and Installation Manual Rev. 2
Copyright © 2015 Access Control Technology Ltd.
Setting Programmable Input Function:
Setting AUX I/O 1 Function:
Setting AUX I/O 2 Function:
I/O Function Codes:
Step Keypad Entry Operation
1 50 Set Input Function (Door Release button is default)
2 00-06
Select 2-digit I/O Function Code (see below for explanation
of codes)
3 1-8 (optional)* Select each door this function is valid for
4
Press
a
End programming Input Function
Step Keypad Entry Operation
1 51 Set AUX I/O 1 Function (Door Contact is default)
2 00-19 Select 2-digit I/O Function Code (see below)
3 1-8 (optional)* Select each door this function is valid for
4
Press
a
End programming AUX I/O 1
Step Keypad Entry Operation
1 52 Set AUX I/O 2 Function (Door Alarm is default)
2 00-19 Select 2-digit I/O Function Code (see below)
3 1-8 (optional)* Select each door this function is valid for
4
Press
a
End programming AUX I/O 2
Step Keypad Entry Operation
00 Door Contact Input required if you wish to monitor Door Forced or Door Ajar
01 Fire Alarm Override
When this input is high, the door is opened and the green LED
ashes (See Fire Alarm Override Connections diagram). If this
is wired into the Master Smart, then all doors on the network
will open.
02 Lock Door When this input is low, the door locks and the red LED ashes.
03 Card and PIN
When this input is low, then only users who enter both Card and
PIN will be admitted. This option is only valid on an ACTsmart2
PIN and PROX unit (1080).
04 Card or PIN
When this input is low, a valid Card or a valid PIN will open the
door. This option is only valid on an ACTsmart2 PIN and PROX
unit (1080).
05 Door Release Button When this input is low, the door opens.
06 Second Door Release Button
07 Interlock
This normally behaves as an input and locks the door while the
input is low. While the door relay is active or the Door Contact
is open, it becomes an active output. (See Interlock Connec-
tions diagram).
08 Door Alarm
This output activates while an alarm is present - A door alarm
may be a door forced, door ajar, tamper or duress.
09 Follow This output follows the state of the door relay.
10 Buzzer This output activates for Door Chime or Door Alarms.
11 Smartlock This output controls a Smart Lock device for Secure doors.
12 Second Door Lock
This output will activate for the Door Relay Time when a valid
card or PIN is presented. See commands 70-73.
12
