Programming ACTsmart2 Prox Only (1070)
To program an ACTsmart2 Prox Only device (1070), a Programming Card must be
assigned to the ACTsmart2. The Programming Card may be any proximity card. If you
have received a batch of cards, it is recommended to use the rst (lowest numbered)
card in the batch as the Programming Card. To set the Programming Card into the
ACTsmart2 Prox do the following:
1. Power up the device with LKI removed and the tamper open (by removing the
main unit from the mounting plate or the surface mount collar).
Within 10 seconds of power up carry out the following actions.
2. Present the card to the reader.
3. Take the card away from the reader for 1 second (more than 20 cm)
4. Within a further 10 seconds replace LKI. The reader will beep.
5. The card is now set as the Programming card. Replace the ACTsmart2 on the
mounting plate /surface mount collar to close tamper.
(Note: ACT recommends using an ACTsmart2 PIN and Prox device (1080) if a network is required). In the steps below, after a card
is presented to the reader it must be taken away from the reader (more than 20cm) for 1 second before presenting the card again.
Adding a Batch Card to the Network:
Deleting Batch Cards from the Network
Deleting Individual Card (Require Card above):
Programming for Default IO:
Step Present Operation
1 Programming Card Add Card Batch. The batch size is restricted to 50 cards.
2 Present Card First card in Batch
3 Present Card Last card in Batch
Step Present Operation
1 Programming Card
2 Programming Card Delete Card Batch
3 Present Card First card in Batch to delete
4 Present Card Last card in Batch to delete
Step Present Operation
1 Programming Card
2 Programming Card
3 Programming Card Delete Individual Card
4 Present Card
Card above the card that needs to be deleted e.g. if card num-
ber 99 needs to be deleted, present card number 100
Step Present Operation
1 Programming Card
2 Programming Card
3 Programming Card
4 Programming Card
5 Present Card
(Not Programming Card) Input 1 = Door Release, AUX I/O 1 =
Door Contact, AUX I/O 2 = Door Alarm
17
