Find Door Number:
Step Keypad Entry Operation
1 61 Find Door Numbers
2 1-8
Enter the door number to be found. The ACTsmart2 assigned
the door number starts to beep.
3 Press a key or present a card To stop the ACTsmart2 beeping.
Adding a Slave to the Network
Another Slave can be added to the network by defaulting it rst (see below) and then
assigning it a door number from the Master.
Removing a Slave from the Network
To remove a Slave unit from the network, simply disconnect it from the network.
Replacing a Slave Unit
To replace a Slave Unit, remove the old Slave from the network. Default the new Slave
and add it to the network. Assign a door number to it from the Master.
Replacing the Master Unit
If the Master Unit needs to be replaced, then replace it with a Slave unit already on
the system, (as it will have all the card/PIN information), and make it the Master. Add
a new, defaulted Slave to the network in place of the swapped-out Slave. Then assign
a Door numbers to the new Slave - make sure it is the Door number of the old Slave.
Restoring Factory Defaults
Enter Programming code followed by 80 followed by a. If this is done on the Master
ACTsmart2 then all ACTsmart2’s on the network are defaulted (including the Master). If
it is done on a Slave then only the Slave is defaulted.
If the programming code has been forgotten, power up with the tamper open (by
removing the main unit from the mounting plate or the surface mount collar), while
holding down the r key. Release the r key and then enter the default Programming
Code (9999).
Defaulting memory takes 3-4 seconds. During this time, the buzzer will sound an
elongated tone.
Find All Door Numbers:
Step Keypad Entry Operation
1 62 Find Door Numbers
2
Press
a
Each ACTsmart2 beeps their door number
3
Press key or present card at each
ACTsmart
To stop the ACTsmart2 beeping.
16
