Step Keypad Entry Operation
1 10 Add Card Batch
2 Present Card First Card in Batch (lowest number card)
3 Present Card Last Card in Batch (highest number card)
4 9 Enable Arming mode (make sure Option 42 is set)
5 1-8, (optional)* Select each door this batch is valid for
6
Press
a
End
Adding a Card Batch with Arming Function:
User Arm Function:
A User with arming capability who presses the ✔ key and then presents a valid card or enters a valid
PIN causes the reader to send a signal to an alarm control panel that may be used to arm/disarm
the panel. This signal is sent via an auxiliary on the reader that is programmed as a “Door Armed
Output”. Option 42 “Arming Door” must be On before the “Door Armed Output” takes effect. If
option 43 Pulse Door Armed is On, a pulsed signal is issued from this output for two seconds. The
control panel in turn may send a signal to the reader to indicate that the panel is armed/disarmed.
This signal is received through an auxiliary on the reader that is programmed as a “Panel Armed
Input”. When this signal is low the door is locked and access is prohibited. Check the alarm panel
wiring diagram at the end of the manual.
To program a card or PIN with the arm function, program as normal, but press 9 before the ✔ key.
See the two examples below:
Step Keypad Entry Operation
1 10 Add Card Batch
2 Present Card First Card in Batch (lowest number card)
3 Present Card Last Card in Batch (highest number card)
4 9 Enable Arming mode (make sure Option 42 is set)
5 1-8, (optional)* Select each door this batch is valid for
6
Press
a
End
Adding a PIN Code with Arming Function:
To summarise, the following steps are required for setting up tokens to arm and disarm alarm
panels:
1. Program the ACTsmart2 to be an Arming Door - Option 42 On
2. Assign a card or PIN with the Arming function - see above.
3. Assign an Aux I/O as the Door Armed output - I/O Function Code 14
4. If required, turn the Pulse Door Armed Option on - Option 43 On
5. If required, assign an input as the Panel Armed input. This input veries when the alarm panel is
actually armed. - I/O Function Code 15
6. Connect up according to the Alarm Panel wiring diagram
