Adaptrum ACRS2.0 Quick Start Guide (International)
CLIENT
For CLIENTs linked to BASE stations configured in “manual database” mode, this tab is unused. However,
it is recommended that users fill in field #2 for future use. For CLIENTs linked to BASE stations
configured in other database modes, field #2 will be required, and the channels available in field #17 and
selectable by button #18 will be constrained by the spectrum oversight agency.
Figure 28: GUI screenshot: CLIENT Database tab
#
FIELD
DESCRIPTION
2
Device Location
Latitude/Longitude/Height of installed unit to be entered by user
17
Scan Channel Set
set of channels selected by button 18
18
Select
pulls down Scan Channel List to allow selection of desired channel set
19
Update Now
updates Scan Channel Set (field #17) after selection by button 18
20
Save & Reboot
saves all changes & causes unit to reboot (puts changes into effect)
Table 10: CLIENT Database Field Descriptions
