Adaptrum ACRS2.0 Quick Start Guide (International)
Systems Specifications
General Specifications
Regulatory Compliance
FCC Part 15 Subpart H
Technology
TDD OFDMA
Network topology
Point to Multi-Point
Mobility Support
Nomadic & Vehicular up to 40 m/s
Frequency Range
400 MHz – 1000 MHz
Channel Bandwidth
Flexible up to 10 MHz
Supporting 6, 7, 8 MHz TV channels
Aggregated Layer 2 Data Rate
(Uplink + Downlink) / 6MHz
1 Mbps – 16 Mbps
Uplink/Downlink Ratio
Any e.g. 1:1, 1:3, 4:1
Transmit Power
100 mW conducted (1 W with external amplifier)
Channel Bandwidth Efficiency
94%
Adjacent Channel Emission
< -55 dBc
Receiver Sensitivity
(6 MHz Channel)
Level
SNR
Data Throughput
-98 dBm
3.5 dB
2.7 Mbps (QPSK 1/2)
-90 dBm
11.5 dB
7.1 Mbps (16 QAM 2/3)
-81 dBm
20.5 dB
12 Mbps (64 QAM 3/4)
Interface Specifications
Integrated Antenna
PCB Bowtie, vertically polarized, 0 dBi
Optional external antenna
connector
SMA Female
Data/Control
10/100 Ethernet Electrical and Mechanical Specifications
Electrical and Mechanical Specifications
Supply
48 V PoE
Physical Dimensions
8.5 inches x 7.5 inches x 1.5 inches
Weight
3.6 LB
Antenna Specifications
PCB Bowtie
Client only, integrated; Vertically polarized, ~0dBi
DB2E UHF Panel
Client or Base, vertically polarized, 2-elements, 6 – 9 dBi
Log-Periodic
Base Only, vertically polarized, 10 dBi
