Specifications
PHYSICAL SPECIFICATIONS
Table 3‑1. Physical specifications
Description Specification
General Physical Specifications
Size For 500 V units, see Table 3‑2
For 690 V units, see Table 3‑3
Weight
Mounting
Mechanical Mounting hardware not included
Connectors
AC auxiliary power supply
input (X1)
Included 3-pin plug-in screw terminal block, 0.2 mm
2
-
2.5 mm
2
(24 AWG - 12 AWG)
RS-232 (powered) (X10) 9-pin subminiature-D socket (for Thyro‑Touch display
connection)
Anybus module (optional) Varies by Anybus module, according to the bus standard (not
included)
dASM module (optional) 2 RJ-45 sockets (connectors and cables not included)
USB (X6) μ USB (connector and cable not included)
Analog I/O 1 (X51) Included 9-pin, plug-in, screw terminal block, 30 AWG -
14 AWG
Analog and digital I/O 2
(X52)
Included 9-pin, plug-in, screw terminal block, 0.14 mm
2
-
1.5 mm
2
(30 AWG - 14 AWG)
Analog and digital I/O 3
(optional) (X53)
Included 16-pin, plug-in, screw terminal block, 0.14 mm
2
-
1.5 mm
2
(30 AWG - 14 AWG)
Analog and digital I/O 4
(optional) (X54)
Included 16-pin, plug-in, screw terminal block, 0.14 mm
2
-
1.5 mm
2
(30 AWG - 14 AWG)
I/O Bus (X4) RJ-45 (connector and cable not included)
24 V DC auxiliary power
supply input (X3)
Included 2-pin, plug-in, screw terminal block, 0.14 mm
2
-
1.5 mm
2
(30 AWG - 14 AWG)
Relay K1 (X21)
Included 3-pin, plug-in, screw terminal block, 0.14 mm
2
-
1.5 mm
2
(30 AWG - 14 AWG)
Thyro-PX
®
Power Controller
Chapter
3
57010148-00G Specifications 3‑1
