• The display can either be connected directly to the power controller, or
connected remotely with the cabinet installation kit.
Warnings are highlighted in yellow, and error messages are highlighted in red on the
display. Click on a warning or an error message to see its details in the fault log.
The following access levels apply:
• Level 1 PIN: 160387, access to parameter settings
• Level 2 PIN: 311263, access to detailed power controller parameterization
Thyro‑Touch Display Menus
The Thyro‑Touch display allows you to access menus and to make menu selections.
When a menu selection causes the display to show a parameter, you can use the
display to set the parameter value.
Accessing the Main Menu
When you connect the display, it shows the information determined by the start
screen configuration.
The Thyro‑Touch display allows you to access menus and to make menu selections.
When a menu selection causes the display to show a parameter, you can use the
display to set the parameter value.
TO ACCESS THE MAIN MENU AND OTHER MENUS
1. Press a soft key to cause another level of menu choices to display.
For example, pressing the list soft key ( ) displays the next menu level:
configure the display and configure the power controller.
2.
Press the home key ( ) to return to the main menu.
SOFTWARE USER INTERFACE
The optional Thyro-Tool Pro software is available for commissioning and
visualization. This software can be used to:
• Update firmware
• Set and display parameters
• Display current operating conditions and events
• Create a time-stamped data record
• Create data charts
Advanced Energy
®
Thyro-PX
®
Power Controller
57010148-00G Communication Controls 4‑13
