Advanced Energy Thyro-PX Series User Manual

Table 3‑1. Physical specifications (Continued)
Description Specification
Relay K2 (X22)
Included 3-pin, plug-in, screw terminal block, 0.14 mm
2
-
1.5 mm
2
(30 AWG - 14 AWG)
Relay K3 (X23)
Included 3-pin, plug-in, screw terminal block, 0.14 mm
2
-
1.5 mm
2
(30 AWG - 14 AWG)
Protection
Degree of protection IP10B
The unit meets IP20 safety of persons requirements, but not the
IP20 safety of device requirements.
Table 3‑2. Type Range 500 Volts
Model
Type Current (A)
Dimensions (WxHxD)
mm (in)
Weight
kg (lb)
Dimensional
Drawing
Thyro-PX 1PX
16 H, 37 H, 75 H, 110 H 150 (5.9) 320 (12.6) 232 (9.1) 6 (13.2) Figure 5‑1
130 H, 170 H 200 (7.9) 320 (12.6) 232 (9.1) 8 (17.6) Figure 5‑2
280 HF 200 (7.9) 370 (14.6) 232 (9.1) 9 (19.8) Figure 5‑3
350 HF, 495 HF, 650 HF 175 (6.9) 501 (19.7) 340 (13.4) 15 (33.0) Figure 5‑4
780 HF, 1000 HF,
1500 HF
242 (9.5) 787 (31.0) 505 (19.9) 35 (77.2) Figure 5‑5
2100 HF 522 (20.5) 577 (22.7) 445 (17.5) 50 (110.2) Figure 5‑6
2900 HF 593 (23.3) 577 (22.7) 473 (18.6) 62 (136.7) Figure 5‑7
Thyro-PX 2PX
16 H, 37 H, 75 H, 110 H 225 (8.9) 320 (12.6) 232 (9.1) 10 (22.0) Figure 5‑8
130 H, 170H 325 (12.8) 320 (12.6) 232 (9.1) 12 (26.5) Figure 5‑9
280 HF 325 (12.8) 415 (16.3 232 (9.1) 15 (33.0) Figure 5‑10
350 HF, 495 HF, 650 HF 261 (10.3) 501 (19.7) 340 (13.4) 22 (48.5) Figure 5‑11
780 HF, 1000 HF, 1500
HF
410 (16.1) 787 (31.0) 505 (19.9) 54 (119.0) Figure 5‑12
2000 HF, 550 (21.6) 837 (33.0) 445 (17.5) 84 (185.2) Figure 5‑13
2750 HF 593 (23.3) 837 (33.0) 474 (18.6) 107 (235.9) Figure 5‑14
Thyro-PX 3PX
16 H, 37 H, 75 H, 110 H 300 (11.8) 320 (12.6) 232 (9.1) 14 (30.9) Figure 5‑15
130 H, 170 H 450 (17.7) 320 (12.6) 232 (9.1) 17 (37.5) Figure 5‑16
280 HF 450 (17.7) 414 (16.4) 232 (9.1) 20 (44.0) Figure 5‑17
Advanced Energy
®
Thyro-PX
®
Power Controller
57010148-00G Specifications 3‑2
