Advanced Energy Thyro-PX Series - COOLING SPECIFICATIONS

Table 3‑6. Type voltage 690 volts (Continued)
Model
Type Current
(A)
Type Power
(kVA)
Dissipation
(W)
Current
Transformer
T1
Burden R
(Ω)
Fuse F1 (A)
2200 HF 2619 9000 3000/1 1.2 4x1400
COOLING SPECIFICATIONS
Type H Thyro-PX power controllers are self cooled, while type HF units are force
cooled. The fan in HF units require a separate power source at 230 V, 50/60 Hz. A
115 V fan is available by special-order for some units.
Table 3‑7. Current derating
Air Temperature I/I
RATED CURRENT
(A)
Self Cooling Forced Cooling
0°C to +25°C (32°F to 77°F) 1.10 1.10
30°C (86°F) 1.10 1.05
35°C (95°F) 1.10 1.00
40°C (104°F) 1.05 0.96
45°C (113°F) 1.00 0.91
50°C (122°F) 0.95 0.87
55°C (131°F) 0.88 0.81
UL applications limited to +40°C (104°F)
Advanced Energy
®
Thyro-PX
®
Power Controller
