Mounting the Unit
1. Install the unit on or in the mounting surface, rack, or cabinet.
2. Fasten the unit to the mounting surface, rack, or cabinet. Use suitable fasteners.
See “Dimensional Drawings” on page 5‑1 for mounting hole details.
Grounding
WARNING:
Do not attempt to turn on power until the chassis of the unit is tied to a local
earth ground through a copper grounding strap that is sized in accordance
with applicable requirements.
AVERTISSEMENT:
Ne pas essayer de mettre l’unité sous tension avant que son ossature ne soit
reliée à une mise à la terre locale à l’aide d’un bracelet de mise à la terre en
cuivre dont les dimensions sont conformes aux exigences applicables.
• Make a suitable chassis ground connection to the location specified on the
dimensional drawing. See “Dimensional Drawings” on page 5‑1.
Connecting I/O and Auxiliary Connectors
DANGER:
RISK OF DEATH OR BODILY INJURY. Disconnect and lockout/tagout all
sources of input power before working on this unit or anything connected to
it.
DANGER:
RISQUE DE MORT OU DE BLESSURES. Débrancher et verrouiller/étiqueter
toutes les sources de puissance d’entrée avant de travailler sur cet appareil
ou sur tout élément qui y est raccordé.
☞ Important
All digital and analog control cables must be shielded. Connect the cable
shields to the shield clamp on the unit as shown in the following figure.
Advanced Energy
®
Thyro-PX
®
Power Controller
57010148-00G Installation, Setup, and Operation 5‑29
