selecting the status line. Simultaneously with the fault signal, you can use the Pulse
Lock On/Off (with acknowledgement), Pulse Lock On/Off (without
acknowledgement), or Regulator Lock On/Off (without acknowledgement)
configuration to require that pulse shutdown occurs. The number and content of
occurred warnings or errors are shown in the status line of the Thyro‑Touch display.
Select a status line to retrieve the corresponding warning or error message.
Minimum and Maximum Monitoring
The following table shows the minimum and maximum conditions that can be
monitored using the Thyro-Tool Pro software.
Table 5‑7. Minimum and maximum conditions
Symbol Description
UMainMin Minimum mains voltage
UMainMax Maximum mains voltage
Ueff_Min Minimum rms voltage
Ueff_Max Maximum rms voltage
U_min Minimum rectified voltage (average of the absolute value)
U_Max Maximum rectified voltage (average of the absolute value)
Ieff_Min Minimum rms current
Ieff_Max Maximum rms current
I_Min Minimum rectified current (average of the absolute value)
I_Max Maximum rectified current (average of the absolute value)
Ip_Max Maximum peak current
P_Min Minimum power
P_Max Maximum power
R_Min Minimum load resistance
R_Max Maximum load resistance
T_Min Minimum power controller temperature
T_Max Maximum power controller temperature
Fuse Monitoring
Open semiconductor fuses are detected and indicated.
Advanced Energy
®
Thyro-PX
®
Power Controller
57010148-00G Installation, Setup, and Operation 5‑47
