Table 3‑4. Electrical specifications (Continued)
Description Specification
Precision U-control: Better than ± 0.5%
I-control: Better than ± 0.5%
P-control: Better than ± 1%
All specifications are relating to the respective final value.
Limitations Voltage limitation U
rms
Current limitation I
rms
= default setting
Effective power limitation P
Peak current limitation, MOSI starting mode
Relays Rated current: 6 A
Rated voltage: 277 VAC, 24 VDC
General use
Contact material: AgNi+Au
Table 3‑5. Type voltage 500 volts
Model
Type Current
(A)
Type Power
(kVA)
Dissipation
(W)
Current
Transformer
T1
Burden
R (Ω)
Fuse F1
(A)
Thyro-PX 1PX
16 H 8 71 400/1 27.4 50
37 H 18 105 100/1 2.7 50
75 H 38 130 100/1 1.30 100
110 H 55 175 100/1 0.91 180
130 H 65 190 150/1 1.10 200
170 H 85 220 200/1 1.10 315
280 HF 140 365 300/1 1.00 350
350 HF 175 477 500/1 1.30 500
495 HF 248 595 500/1 1.00 630
650 HF 325 750 700/1 1.00 900
780 HF 390 1180 1000/1 1.00 2x700
1000 HF 500 1450 1000/1 1.00 2x1000
1500 HF 750 1775 1500/1 1.00 4x900
2100 HF 1050 2600 2000/1 0.91 4x1000
Advanced Energy
®
Thyro-PX
®
Power Controller
57010148-00G Specifications 3‑5
