Table 3‑5. Type voltage 500 volts (Continued)
Model
Type Current
(A)
Type Power
(kVA)
Dissipation
(W)
Current
Transformer
T1
Burden
R (Ω)
Fuse F1
(A)
2900 HF 1450 3400 3000/1 1.00 4x1500
Thyro-PX 2PX
16 H 14 107 400/1 27.4 50
37 H 32 175 100/1 2.70 50
75 H 65 220 100/1 1.30 100
110 H 95 310 100/1 0.91 180
130 H 112 350 150/1 1.10 200
170 H 147 410 200/1 1.10 315
280 HF 242 700 300/1 1.00 350
350 HF 303 889 500/1 1.30 500
495 HF 429 1150 500/1 1.00 630
650 HF 563 1465 700/1 1.00 900
780 HF 675 2320 1000/1 1.00 2x700
1000 HF 866 2865 1000/1 1.00 2x1000
1500 HF 1300 3510 1500/1 1.00 4x900
2000 HF 1732 4800 2000/1 1.00 4x1000
2750 HF 2381 6200 3000/1 1.00 4x1500
Thyro-PX 3PX
16 H 14 228 400/1 27.4 50
37 H 32 330 100/1 2.70 50
75 H 65 400 100/1 1.30 100
110 H 95 540 100/1 0.91 180
130 H 112 560 150/1 1.10 200
170 H 147 650 200/1 1.10 315
280 HF 242 1070 300/1 1.00 350
350 HF 303 1301 500/1 1.30 500
495 HF 429 1800 500/1 1.00 630
650 HF 563 2265 700/1 1.00 900
780 HF 675 3330 1000/1 1.00 2x700
1000 HF 866 4370 1000/1 1.00 2x1000
1500 HF 1300 5335 1500/1 1.00 4x900
1850 HF 1602 6900 2000/1 1.00 4x1000
