Table 3‑10. Climatic specifications (Continued)
Temperature Relative Humidity Air Pressure
Storage -25°C to +55°C
-13°F to +131°F
5% to 95%
1 g/m
3
to 29 g/m
3
78.8 kPa to 106 kPa
788 mbar to 1060
mbar
Equivalent altitude:
+2000 m to ‑500 m
(+6562′ to ‑1640′)
Transportation -25°C to +70°C
-13°F to +158°F
95%
[3]
60 g/m
3 [4]
65.6 kPa to 106 kPa
656 mbar to 1060
mbar
Equivalent altitude:
+3500 m to ‑500 m
(+11480′ to ‑1640′)
1
Non-condensing, no formation of ice
2
Operation at higher altitudes is possible with reduced current limits. From +1000 m to +2000 m
(+3281′ to +6562′), the rated current is decreased by 1.5%/100 m (1.5%/328′). Contact AE Global
Services for operating at >+2000 m (+6562′).
3
Maximum relative humidity when the unit temperature slowly increases, or when the unit temperature
directly increases from -25°C to +30°C (-13°F to +86°F)
4
Maximum absolute humidity when the unit temperature directly decreases from +70°C to +15°C
(+158°F to +59°F)
TYPE DESIGNATION
The type designations of the Thyro-PX power controllers are derived from the
construction of the unit power section, as shown in the following table.
Table 3‑11. Type designation
Type Range Designation Features
Thyro-PX
power
controller
1PX 1-phase power section, for 1-phase operation
2PX 2-phase power section used with a 3-phase
load in 3-phase economic circuit (not for
phase-angle firing VAR), or with two 1-phase
loads in multi-zone mode
3PX 3-phase power section, for 3-phase operation,
or with three 1-phase loads in multi-zone
mode
