Advanced Energy Thyro-PX Series User Manual

Table 4‑6. 16-pin digital I/O connector (X53 or X54) (Continued)
Pin Signal Name Function
X54.4 Digital input 3.2 User configured
X54.5 Digital input 3.3 User configured
X54.6 Digital input 3.4 User configured
X54.7 Digital input 3.5 User configured
X54.8 Digital input 3.6 User configured
X54.9 Digital input 3.7 User configured
X54.10 Digital input 3.8 User configured
X54.11 Digital input 3.9 User configured
X54.12 Common
X54.13 Digital output 3.1 User configured
X54.14 Digital output 3.2 User configured
X54.15 Digital output 3.3 User configured
X54.16 Common
The unit has six standard I/O connectors on the bottom of the unit:
• RJ-45 I/O bus
• Fault relay K1
• Limit relay K2
• Optional relay K3
• 24 V auxiliary power supply input
• AC auxiliary power supply input
Advanced Energy
®
Thyro-PX
®
Power Controller
57010148-00G Communication Controls 4‑8
