Advanced MxPro4

11
2 Installation
2.1 Identification of Parts
The following diagrams show the major parts of the panels.
2.1.1 Mx-4200V & Mx-4400V
2.1.2 Mx-4400V/LE
Earth Lead to
Cover
Chassis Assembly
Loops 1 - 4
Rear Enclosure
Door
Battery Shelf
Loops 1 - 4
Bus-bars for cable earth
connections
Viewing Window
for Loops 1-4
Additional
Battery Shelf
Chassis
Assembly
Rear
Enclosure
AC Mains
Input
Battery
Leads
