3.3.17.7 Earth Fault Notification

This parameter determines whether an Earth Fault is shown on the display during normal operation. To change

the setting, press the ✔ button. The status changes from ✔ to X and vice versa.

3.3.17.8 Routing Interface

This parameter determines whether the panel supports a fire and / or fault routing interface. It is possible to

select between no routing interfaces, monitored routing interfaces (requires installation of the Routing Interface

Peripheral Card and non-monitored routing interface using the on-board fire and fault relays. To change the

setting, press the ✔ button. With each press, the option cycles between X, Monitored and Non-Monitored.

When a routing option is selected, Function LED1 (Red) is used to indicate that the Fire Routing Output is

activated and Function LED2 (Yellow) is used to indicate that the Fire Routing Output is disabled. If the

monitored option is selected, Function LED3 (Yellow) is used to indicate a fault in the transmission path of the

fire routing connection. Function LED3 will also illuminate if there is a fault on the routing interface or if the

routing interface card is not present.

If a routing option is selected, these function LED indicators are reserved for these indications and are not

available for other programmable indication use.

By default, the fire routing output (panel internal addresses – 11.1 unmonitored & 16.0 monitored) and the fault

routing output (panel internal addresses 11.0 unmonitored & 17.0 monitored) are assigned to Output Groups

199 & 200, respectively. These can be assigned to alternative output groups using the "Panel" menu option if

required.

By default, the fire routing output will be activated if there is fire in any zone. The output is configured not to turn

on in the event of a fire test even if the output group rule contains this option.

By default, the fault routing output will be turned off if there is a fault in any zone.

3.3.17.9 Program ID

The display shows the part number and version of the software installed in the panel. Press the  button to see

the program checksum (8 digits)

3.3.17.10 Config Data

The Config Data option shows the loop protocol and the checksum for the configuration data. A note of this

number can be taken and then checked on the next service visit to see if any changes have been made to the

configuration data.

In addition, there is an option to erase the Config Data.

To view the Config Data Checksum, press the  button. The display then shows:

[Setup]

CONFIG DATA :VEGA More>
