107 AIMB-286 User Manual
Appendix A I/O Pin Assignments
A.7 Platform Controller Hub (PCH1)
A.8 RJ45 1 Port (LAN1)
Pin Signal Pin Definition
1LAN1_MDI0+
2LAN1_MDI0-
3LAN1_MDI1+
4LAN1_MDI1-
5LAN1_CONN
6LAN1_CT
7LAN1_MDI2+
8LAN1_MDI2-
9LAN1_MDI3+
10 LAN1_MDI3-
11 LAN1_LED0_ACT#_R
12 +V3.3_DUAL
13 LAN1_LED1_1G#_R
14 LAN1_LED2_100M#_R
