1.1 Introduction
AIMB-286 is designed with the Intel® H310 PCH for industrial applications that
require both performance computing and enhanced power management capabilities.
The motherboard supports Intel desktop Corei7/i5/i3/Pentium/Celeron processor up
to 12 MB SmartCache and 2 DDR4 2666MHz SO-DIMM, up to 32 GB. A rich I/O con-
nectivity of 6 x serial ports, 4 USB 3.0 + 4 USB 2.0, 3 GbE LAN, 3 SATA III, 1 NGFF
(M.2_E key) and 1 x NGFF (M.2_B Key) Connector.
1.2 Features
 Rich I/O connectivity: 6 x serial ports, 4 x USB 3.0, 4 x USB 2.0, 3 x SATAIII, 1
M.2 B key & 1 M.2 E key, 3 GbE LAN and 1 PCIe x 4
 Standard Mini-ITX form factor with industrial feature: The AIMB-286 is a full-
featured Mini-ITX motherboard with balanced expandability and performance
 Wide selection of storage devices: SATA HDD, M.2 (B key), customers bene-
fit from the flexibility of using the most suitable storage device for larger capacity
 Optimized integrated graphic solution: With Intel® Graphics Flexible, it sup-
ports versatile display options and 32/64 bit 3D graphics engine
1.3 Specifications
1.3.1 System
 CPU: LGA1151 Intel desktop Core i7/i5/i3/Pentium/Celeron processors compliant
 BIOS: AMI EFI 128 Mbit SPI BIOS
 System chipset: Intel® H310
 SATA hard disk drive interface:
– Three on-board SATA connector with data transmission rate up to 600 MB
– One M.2 B key for storage with data transmission rate up to 600 MB
1.3.2 Memory
 RAM: 2 x 260-pins SODIMM socket support dual channel DDR4 2666MHz
SDRAM, up to 32GB Max.
1.3.3 Input/Output
 PCI bus: 1 x PCIe x4 slot
 Serial ports: Six serial ports; COM1/4/5/6: RS-232, COM2/3: RS-232/422/485
(RS-422/485 supports by BOM option)
 Keyboard and PS/2 mouse connector: Supports one standard PS/2 key-
board, one standard PS/2 mouse
 USB port: Supports four USB 3.0 port with a transmission rate of up to 5Gbps
and four USB 2.0 ports with transmission rates of up to 480 Mbps.
 GPIO connector: 16-bit general purpose Input/Output
1.3.4 Graphics
Note! USB 3.0 for USB4 is only available when M.2 B key USB 3.0 is not in
use; USB 3.0 for USB4 and M.2 B key USB 3.0 cannot be used concur-
rently.
