21 AIMB-286 User Manual
Chapter 2 Connecting Peripherals
2.13 eDP/LVDS Panel Connector (LVDS_EDP1)(eDP
support by BOM optional)
2.14 LVDS/eDP Backlight Inverter Power Connector
(INV1)
LV D S 1
Pin 3: GND -> Panel connected
NC/3.3V -> No panel
Note! Signal Description
Signal Signal Description
VR Vadj=0.75 V
(Recommended: 4.7 K, 1/16 W)
ENBKL LCD backlight ON/OFF control signal)
