109 AIMB-286 User Manual
Appendix A I/O Pin Assignments
A.11 Battery Wafer Box (BAT1)
A.12 HD Analog Audio Interface (AUDIO1)
A.13 HD Analog Audio Interface (AUDIO2)
Pin Signal Pin Definition
1 VBAT
2GND
Pin Signal Pin Definition
1 LINE-OUT
Pin Signal Pin Definition
1MIC
