AIMB-286 User Manual 4
Table 1.1: Connector and Header List
Description Location Name
1 DC input Phoenix Connector DCIN1
2 DisplayPort DP1+HDMI1
3 High Definition Multimedia Interface DP1+HDMI1
4 ATX Power supply (5VSB) connector ATX_5VSB1
5 USB 3.0 Stack Connector USB12
6 USB 3.0 Stack Connector USB34
7 RJ45 2 port LAN12
8 Platform Controller Hub PCH1
9 SATA Signal Connector SATA1/2/3
10 RJ45 1 port LAN3
11 Battery Wafer Box BAT1
12 HD Analog Audio Interface: Line-Out AUDIO1
13 HD Analog Audio Interface: MIC AUDIO2
14 Front HD Analog Audio Interface FPAUD1
15 Audio Amplifier Output Connector AMP1
16 HD Digital Audio Interface SPDIF1
17 PCI-E x 4 Slot PCIEX4_1
18 NGFF M.2 E-Key connector for 2230 module M2E1
19 NGFF M.2 B-Key connector for 2242/3042 module M2B1
20 USB 2.0 Connector USB56/USB78
21 General Purpose I/O Pin Header GPIO1
22 DDR4 SO-DIMM Socket DIMMA1/DIMMB1
23 COM 4 Port COM3456
24 PS/2 Keyboard and Mouse Connector KBMS1
25 Low Pin Count Header LPC1
26 COM 2 Port COM12
27 Power LED and Keyboard Lock Pin Header JFP2
28 Case-Open Detect Connector JCASE1
29 SPI Programming Pin Header SPI_CN1
30 SPI BIOS Flash Socket SPI1
31 SYSTEM FAN Power Connector SYSFAN1/SYSFAN2
32 TI’s SMBUS Programming for +Vcore/+VCCGT Controller JSMB1
33 LGA1151 CPU Socket H4 CPU1
34 CPU FAN Power Connector CPUFAN1
35 eDP/LVDS Backlight Inverter Power Connector INV1
36 SATA Power Connector
SATA_PWR1/
SATA_PWR2
37 eDP/LVDS Panel Connector LVDS_EDP1
38 ATX 12V Power Supply Connector ATX12V1
39 SIM Card Connector SIM1
40 Buzzer SP1
41 CPU Back Plate CPU0_BACKPLATE1
