v AIMB-286 User Manual
CPU Compatibility
Memory Compatibility
Ordering Information
* ( ) is not populated when MP
Processor Number Max_TDP Code Name Cores/Threads S-Spec Lithography
i7-8700 65W Coffee Lake 6C/12T SR3QS 14nm
i5-8500 65W Coffee Lake 6C/6T SR3XE 14nm
i3-8100 65W Coffee Lake 4C/4T SR3N5 14nm
G5400 54W Coffee Lake 2C/4T SR3X9 14nm
G4900 54W Coffee Lake 2C/2T SR3W4 14nm
i7-8700T 35W Coffee Lake 6C/12T SR3WX 14nm
i5-8500T 35W Coffee Lake 6C/6T SR3XD 14nm
i3-8100T 35W Coffee Lake 4C/4T SR3X8 14nm
G5400T 35W Coffee Lake 2C/4T SR3XB 14nm
G4900T 35W Coffee Lake 2C/2T SR3YP 14nm
Category Speed Capacity Vendor Chip_PN ADVANTECH P/N ECC
DDR4 2666 8GB Advantech
SEC 737 K4A4G08
5WE BCTD
SQR-
SD4N8G2K6SNEEB
N
DDR4 2400 16G Advantech
SEC 749 K4A8G08
5WB BCRC
SQR-
SD4M16G2K4SNBB
N
DDR4 2400 4G Advantech
SEC 749 K4A4G08
5WE BCRC
SQR-
SD4M4G2K4SNEEB
N
DDR4 2666 4G Advantech
SEC 807 K4A4G08
5WE BCTD
SQR-
SD4N4G2K6SNEEB
N
DDR4 2133 16G Advantech
SEC 546 K4A8G08
5WB BCPB
AQD-SD4U16N21-
SE
N
DDR4 2133 8G Advantech
SEC 552 BCPB
K4A4G085WD
AQD-SD4U8GN21-
SG
N
DDR4 2400 8G Advantech
H5AN8G8NAFR
UHC 643V
SQR-SD4N-
8G2K4HBC
N
DDR4 2400 16G Advantech
H5AN8G8NAFR
UHC 643V
SQR-SD4N-
16G2K4HBC
N
DDR4 2400 16G Advantech
H5AN8G8NAFR
UHC
AQD-SD4U16N24-
HE
N
P/N
Chip-
set
DP1.2
LVDS/
eDP
HDMI
1.4
GbE
LAN
COM SATAIII
USB3.
0/2.0
M.2 B
key
M.2 E
key
PCIex4 TPM AMP
AIMB-286F-
00A1E
H310 1 1/ (1) 1 3 6 3 4/4 1 1 1 (1) (1)
AIMB-286G2-
00A1E
H310 1 1/ (1) 1 2 2 3 4/4 1 1 1 (1) (1)
AIMB-286L-
00A1E
H310 1 0 1 1 2 2 4/0 1 1 0 0 0
