FWA-3260 User Manual v02_20160302.docx Copyright 2014 Advantech Co. Ltd. All rights reserved. Page 35
Figure 14: DIMM Location
Location
DIMM
Channel
Color
SMBus Adr.
A0
CN1
A
Black
0xA0
A1
CN2
A
Black
0xA2
B0
CN3
B
Black
0xA4
B1
CN4
B
Black
0xA6
Table 11: DIMM mapping
DIMM modules need to be populated in A1 or B1 as first priority. DDR4 modules will be
recognized automatically. No manual adjustment is required.
It is recommended to use identical DIMMs on both sockets for best performance and
reliability.
The following list summarizes the modules validated on the FWA-3260:
Vendor
Frequency
Capacity
Advantech PN
Advantech
DDR4-2133
4G
AQD-D4U4GR21-SG
DDR4-2133
8G
AQD-D4U8GR21-SG
DDR4-2133
16G
AQD-D4U16R21-SE
Table 12: Validated DIMMs
Please contact you Advantech representative for the most recent list of validated peripherals
or if you would like to use modules not listed.
2.4.6 Chipset
The chipset / PCH functionality is integrated into the Xeon D SoC.
2.4.6.1 USB
The FWA-3260 supports two external USB2.0/3.0 ports which can be used to connect
low, full and high speed devices. The 5V supply rail supplied to external devices is
current limited by a self resetting, electronic fuse to 500mA.
USB Port
USB Type
Implementation
0/1
2.0/3.0
Type A front panel connector
1/2
2.0/3.0
Type A front panel connector
3
2.0
USB header (reserved)
5/6
3.0
USB header (reserved)
Table 13: USB Ports
