Advantech FWA-3260 - Table 26: Platform Setup: COM1 Console Redirection Menu Items; USB Configuration

FWA-3260 User Manual v02_20160302.docx Copyright 2014 Advantech Co. Ltd. All rights reserved. Page 56
Stop Bits
1 / 2
Defines number of stop bits in a character.
Flow Control
None / Xon/Xoff
Defines the flow control scheme.
VT-UF8 Combo
Key
Disabled /
Enabled
Enables VT-UTF8 Combination Key Support for ANSI /
VT100 terminals
Recorder Mode
Disabled /
Enabled
When Enabled the data displayed on a terminal will be
captured and sent as text messages to a remote server.
Resolution
100x31
Disabled /
Enabled
Enables or disables extended terminal resolution
Legacy OS
redirection
80x24 /
80x 25
When using Legacy OS, this item specifies the Number of
Rows and Columns supported
PuTTY Keypad
VT100 /. LINUX /
XTERMR6 / SCO
/ ESCN / VT400
Select Function Key and Key Pad Emulation on PuTTY.
Redirection after
BIOS
Always Enable /
BootLoader
This defines how long console redirection will be active:
“BootLoader” means that legacy console redirection is
disabled before booting into a Legacy OS. “Always Enable”
means Legacy console Redirection is enabled
permanently.
Table 26: Platform Setup: COM1 Console Redirection Menu Items
3.2.2.2 USB Configuration
This sub menu allows you to change the settings used for USB and to get an overview of the
USB devices detected by the BIOS.
