FWA-3260 User Manual v02_20160302.docx Copyright 2014 Advantech Co. Ltd. All rights reserved. Page 42
00:1F:00
8086:8C54
Intel LPC
device
Intel LPC device
00:1F:03
8086:8C22
Intel SMBus
Intel SMBus controller
00:1F:02
8086:8C06
Intel SATA1
Intel SATA controller
00:1F:05
8086:8C08
Intel SATA
Intel SATA controller
02:00:00 - 03
8086:6F51-6F53
Intel QuickData
Technology
DMA Channel 0 to Channel 3
03:00:00
8086:15AC
Intel Lan
controller
Intel BoradWell-DE LAN Controller
05:00:00
8086:1521
Intel I350 LAN
Onboard I350 LAN device #1
05:00:01
8086:1521
Intel I350 LAN
Onboard I350 LAN device #2
05:00:02
8086:1521
Intel I350 LAN
Onboard I350 LAN device #3
05:00:03
8086:1521
Intel I350 LAN
Onboard I350 LAN device #4
06:00:00
8086:1533
Intel I210 LAN
Onboard I350 LAN device #1
07:00:00
8086:1533
Intel I210 LAN
Onboard I350 LAN device #2
08:00:00
1A03:1150
Aspeed PCI
Express Root
Port
Aspeed PCIe Root Port
09:00:00
1A03:2000
Aspeed VGA
Onboard VGC
Table 18: PCIe devices
2.4.13 Platform Management
A Nuvoton NCT7904 Hardware Monitor Chip (HWM) provides hardware monitoring
capabilities on the FWA-3260. The HWM chip is connector to the PCH’s SMBus. Standard
software packages such as “lmsensors” can be used on the host to provide sensor
information under Linux. Advantech provides the required patch that adds support for the
HWM chip and a system specific configuration file.
Please contact your Advantech representative if you wish to receive the lmsensors patch or,
in case you want to implement your own hardware monitoring solution, to obtain more
details regarding the hardware implementation.
The HWM monitors all critical voltages on the FWA-3260:
