Advantech FWA-3260 - Figure 43: Server Mgmt Configuration; Table 41: Server Mgmt Configuration Menu Items

FWA-3260 User Manual v02_20160302.docx Copyright 2014 Advantech Co. Ltd. All rights reserved. Page 75
Figure 43: Server Mgmt configuration
Group
Setup item
Access /
Options
Description
None
BMC Self Test
Status
Display only
(Passed)
BMC self test status indication during
power on process
OS Watchdog
Timer
Enable
Disable
If enabled, starts a BIOS timer which can
only be shut off by Management Software
after the OS loads.
Helps determine that the OS successfully
loaded or follows the OS Boot Watchdog
Timer
OS Wtd Timer
Timeout
5 minutes
10 minutes
15 minutes
20 minutes
Configure the length of the OS Boot
Watchdog Timer. Not available if OS Boot
Watchdog Timer is disabled.
OS Wtd Timer
Policy
Do Nothing
Reset
Power Down
Configure how the system should respond
if the OS Boot Watchdog Timer expires.
Not available if OS Boot Watchdog Timer is
disabled.
Table 41: Server Mgmt configuration Menu Items
