FWA-3260 User Manual v02_20160302.docx Copyright 2014 Advantech Co. Ltd. All rights reserved. Page 38
SMBu
s
Adr,
Device
Function
0
0x5A/5C
NCT7904D
Hardware monitor chip
0
0xA0
DIMM A0 SPD
SPD EEPROM
0
0xA2
DIMM A1 SPD
SPD EEPROM
0
0xA4
DIMM B0 SPD
SPD EEPROM
0
0xA6
DIMM B1 SPD
SPD EEPROM
0
0xAC
24C02
System FRU EEPROM
Table 17: SMBus Devices
Most of the SMBus devices are only accessed by BIOS at system start up to determine and
set system configuration. Tampering with these devices may lead to system instability and
malfunction.
Information on the hardware monitor and how to access it is provided in section 2.4.13.
Information reg. the FRU EEPROM can be found in section 2.4.14.2.
2.4.7 Network interfaces (onboard)
The FWA-3260 supports a total of 6 network ports copper and 2 10G SFP+ port fiber on
board.
There are 2 i210 GbE LAN device for management(locations F6), and 1 i350 for “traffic”
ports(locations F7), the i210 is a single LAN chip and i350 GbE LAN device is a four port LAN
chip, compact, low power components that offer a fully integrated Gigabit Ethernet Media
Access Control (MAC) and Physical Layer (PHY) port.
The i210 LAN chip and i350 LAN chip are connected from integrated PCH PCIe port. The LAN
chip can support PCIe Gen1 and 10/100/1000 Mb/s.
The X552 10G MAC integrated in Broadwell-DE SoC package, and it connect with external
PHY CS4227 (10GbE SFP+ PHY) to support 2 SFP+ connector on board in front IO(locations
F5).
2.4.8 PCIe Expansion
A std PCIex8 slot as add on card expansion module in rear pane(locations R1) . The
expansion slot supports 1 PCIex8 gen.3 connectivity. (2 PCIex4 on request)
