•  -Increasestheashingparameterbeingdisplayed.Tomoveaboutthe
listofintervalinsulationmeasurements,intheR(t)function.
•  -Decreasestheashingparameterbeingdisplayed.Tomoveabout
thelistofintervalinsulationmeasurementsintheR(t)function.
 Ifthe and buttonsarehelddown,themovementbetweenparam-
etersisincreasedtoafasterrate.
Model 5060 only:
• MEM-Savesmeasuredvalues
• MR-Recallssaveddata
• PRINT-Printsmeasurementresults
• PRINT MEM-Printsmemorycontents
2.2 Digital Features
8.8.8.8
0
.
1
M
1
M
1
0
M
1
0
0
M
1
G
1
0
G
1
0
0
G
1
T
µA nA µF
COM
P
GΩ
PI
DARDD
ALARM
TΩ
MΩ kΩ
MEM MR
SMOOTH REMOTE
OBJ.
min sec
TEST
V
DC
AC
2
nd
8.8.8.8
Main Display
Indicatesthevalueof:
• Insulationmeasurement(resistance,DARandPI,DD,capacitance).
Small Display
Indicates:
• Voltagemeasuredorappliedbytheinstrument.
• Elapsedtimeortheoutputvoltage,duringinsulationmeasurement.
Afterrecordingasetofdata(5060),thesmalldisplayalsoindicatesthetimeand
dateinMR(memoryrecall)mode,andthememoryaddresswiththeOBJ:TEST
number.
