AEMC 5050 - Bargraph; Symbols

10 Megohmmeter Models 5050/5060
2.3 Bargraph
• Activeduringinsulationmeasurement(0.1MΩ to 1TΩ).
• Indicatesthebatterychargeatstart-up.
• Indicatesfreememoryspace-onesegmentrepresentingapproximately
100groupsofsavedvalues,witheachgroupholdingapproximately50
recordings(1OBJand1TEST).
2.4 Symbols
MEM/MR:Memoryaddress(5060)-indicatesthememoryoperation.
OBJ:TEST: Memoryaddress(5060)-thenumberisdisplayedonthesmalldigital
display.
COM:Flashesonthescreenwhendataistransmittedtotheserialinterface(5060)
orremainspermanentlydisplayedifthereisaproblemduringtransfer.
DAR/PI/DD: Indicates the mode chosen before insulation measurement or the
resultsofthesemeasurements.
Dangerousvoltagegenerated;V>120V.
Externalvoltagepresent,symbolisactivatedafterpressingSTART,ifV
>25VAC±3Vor>35VDC.
Activationof“time-controlledtest”modeorclockadjustmentwhenin
SET-UP(5060).
(Yellowbutton)Selectsthesecond(bottom)functionofabutton.
Flashesifthebatteryvoltageislow,indicatingthatthebatteryshould
berecharged(see§8.1).Thevoltageisdisplayedonthesmalldisplay
for 2 seconds when the instrument is turned on. The main display
indicates“bat”whenthetestiscarriedon.
Warningbuzzerisactivated.
Indicatesthattheautomaticswitch-o󰀨functionhasbeendeactivated.
SMOOTH:Smoothstheinsulationmeasurementsdisplayed.
REMOTE: Remotecontrol viaan interface(5060).In thismode,allthebuttons
andtherotaryswitchontheinstrumentarenon-functional,exceptfor
theOFFposition.
FUSE -G-: Flashesifthe“G”inputfuseisdefective.
