38 Megohmmeter Models 5050/5060
Second Function - MR
TheMRfunctionallowsarecallofanysaveddatafrommemory,regardlessofthe
positionoftherotaryselectorswitch.
• Whenthebuttonispressed,theMRsymbolisdisplayed.Thesmalldis-
playindicatesthelastOBJ : TESTnumbertobeassigned(e.g.02:11).
• 02“11”ashesoppositetheTESTsymbol.Usethe and buttonsto
selectthedesiredOBJ : TESTnumber.
• If a new OBJ is selected, TEST is automatically set to the maximum
storednumber.Atthisstage,itispossibletoreviewtheentirememory
withthe and b uttons,sincethemeasurementvaluescorresponding
totheselectedOBJ : TESTnumberaredisplayedonthemaindisplay.
UsetheR-DAR-PI-DDbuttontoscrollthroughthem.
• The V/TIMEbuttongivesaccesstothedate/time/V /OBJ-TESTnumber
foreachresult.
• Iftherecording selectedbytheOBJ : TESTnumbercorrespondstoa
time-controlled test, the R(t) values can be accessed by pressing the
R(t)button.Thesmalldisplaychangesandindicatesmin:sec(timeof1st
sample)andthesymbol ashesonthescreen.Youcanscrollthrough
theothersampleswiththe button.
ToexitfromR(t) modeandreturntothenormalmemoryrecallmode(OBJ : TEST),
press R(t) or R-DAR-PI-DDagain.
To exit the MR function,pressMRbuttononceagainorturntheselectorswitch.
6.3 Printing Measured Values
(PRINT/PRINT MEM Button - Model 5060)
If you use a serial printer, choose the appropriate communication speed (baud
rate)intheSET-UPmenu,between300-9600baud,thenprogramtheprinterto
theformatrunbytheinstrument(see§6.1).
Therearetwoprintingmodespossible:
• Instantaneousprintingofmeasurement(PRINT)
• Printingofrecordeddata(PRINTmemory)
NOTE: If the data transmission to the printer is successful, the COM symbol
flashes once on the screen. If a problem has occurred, the COM symbol
remains on the LCD screen without flashing.
