1.2 Definition of Measurement Categories
CAT II: For measurements performed on circuits directly connected to the
electricaldistributionsystem.Examplesaremeasurementsonhousehold
appliancesorportabletools.
CAT III: Formeasurementsperformedinthebuildinginstallationatthedistribution
level such as on hardwired equipment in xed installation and circuit
breakers.
CAT IV: Formeasurementsperformedattheprimaryelectricalsupply(<1000V)
suchasonprimaryovercurrentprotectiondevices,ripplecontrolunits,
or meters.
1.3 Receiving Your Shipment
• Matchthecontentswiththeorderinginformation.
• Notifyyourdistributorofanymissingitems.
• Iftheequipmentappearstobedamaged,leaclaimimmediatelywiththe
carrierandnotifyyourdistributoratonce.
NOTE: Charge the instrument fully before use.
1.4 Ordering Information
Megohmmeter Model 5050.............................................................Cat. #2130.20
Includes extra large classic tool bag, set of three 10 ft (5kV) leads (red/black/blue) with
integral 5000V rated hippo clips, one guard terminal jumper lead, US 115V power cord,
rechargeable battery pack, and user manual.
Megohmmeter Model 5060.............................................................Cat. #2130.21
Includes extra large tool bag, set of three 10 ft (5kV) leads (red/black/blue) with integral
5000V rated hippo clips, one guard terminal jumper lead, RS-232 DB9 F/F 6 ft null modem
cable, RS-232 to USB adapter, US power cord, rechargeable battery pack, and a USB stick
with DataView
®
software and user manual.
1.4.1 Accessories and Replacement Parts
Cable,PCRS-232,DB9F/F6ftNullModemCable(5060)............. Cat. #2119.45
Setof3,Color-coded10ftSafetyLeads(5000V),3Color-coded
AlligatorClips(600VCATIV) ........................................................... Cat. #2119.76
Lead–Replacement1ftjumperlead............................................... Cat. #2119.78
Fuse,Setof5,0.1A,380V,5x20,.10kA ......................................... Cat. #2119.84
