AEMC 5050 - Clearing the Memory; Communication Rate (RS-232); Default Device Configuration

20 Megohmmeter Models 5050/5060
2.5.8 Clearing the Memory
In SET-UP,presstheMEMbutton:
• TheMEMsymbolashes
• Thesmalldisplayindicates“ALL”
• Themaindisplayindicates“cLR”
To clear the entire memory,presstheMEMbuttonagainfor2seconds:
• TheMEMsymbolisdisplayedwithoutashing
• Thesmalldisplayindicates“ALL”
• Themaindisplayindicates “FrEE”
To clear the contents of a specic OBJ : TEST number:
• Selectthenumberusingthe and buttons
• “FrEE” or “OCC” appearsonthemaindisplay
PresstheMEMbuttonagainfor2secondstoclearthecontents:
• ThesmalldisplayindicatestheOBJ : TESTnumber
• Themaindisplayindicates “FrEE”
2.5.9 Communication Rate (RS-232)
• In SET-UP,pressthePRINTbutton.
• ThemaindisplayindicatestheCommunicationRate(e.g.300,600,1200,
2400,4800,9600orParallel).
• “bAUd”appearsonthesmalldisplay.Thevaluecanbechangedusing
the and buttons.
• “Parallel” appearing in the display means that the parallel mode has
beenselected.Thisisforprintingonaparallelprinterviatheserial-to-
paralleladapter(RS-232Centronics).
2.5.10 Default Device Configuration
In SET-UP,pressthe buttonthreetimes:
• “SEt” appearsinthesmalldisplay.
• “DFLt”(ashing) appearsinthemaindisplay.
PressSTARTtoselectthedefaultcongurationsettings(seetheprevioustable).
