AEMC 5050 - Smooth Button; UP;DOWN Button

Megohmmeter Models 5050/5060 17
• Pressthe RightArrow KeyagaintomovetotheResistance ValueSet
Point Selection. You can change this value digit by digit using the Up
Arrow/LeftArrowcombinationworkingfromthehighesttolowestdigit.
• Whennishedprogrammingthealarmsettings,placetherotaryswitchto
thedesiredtestfunction.
• Beforeinitiatingatest,presstheYellow2
nd
buttonandtheAlarmbutton
toactivatetheAlarmNotication.Theword“ALARM”willappearinthe
lowerleftsideofthedisplay.
• Next,presstheroundyellowStart/Stopbuttontobeginthetest.TheAlarm
symbolwillashandthebuzzerwillsoundcontinuouslyiftheAlarmset
pointistripped.
NOTE: If the rotary switch is turned off prior to the next test, the alarm notification
will be deactivated. You will need to press the Yellow 2
nd
button and the Alarm
button to activate the Alarm Notification when you turn the unit back on before
starting the next test, if alarm notification is desired.
2.5.5 / Smooth Button
First Function -
Selectsthedesiredparametertobemodied-theselectedparameterashes.
Theashingparameterismodiedusingthe button(see§2.5.6).
Second Function - SMOOTH
Activatesadigital lterforinsulation measurement.Itonly hasane󰀨ect onthe
displayedvalues(whicharesmoothed)andnottheactualmeasurements.
Forexample,thisfunctionisusefulwhenthedisplayedinsulationvaluesarehighly
unstable,broughtaboutduetoacapacitivecomponentinthetestedelement.
2.5.6 Button
Changestheashingparametersdisplayed,orviewsR(t)values(see§2.5.3).
Asageneralrule,twogures(day,month,hour,min.,sec.,andOBJ:TEST)ash.
The and functionshavea“follow-on”mode.(e.g.assoonasthehighorlow
programlimitisreached,theparametertobemodiedswitchesautomaticallyto
thefollowingloworhighlimit.)
