AEMC 5050 - Instantaneous Printing Of Measurements (Print Button)

Megohmmeter Models 5050/5060 39
6.4 Instantaneous Printing of Measurements (PRINT button)
FollowingameasurementorafteraccessingvaluesinMRmode,usethePRINT
functiontoprintthemeasurementresults.
NOTE: PRINT only works when the test is stopped by pressing the START/STOP
button and the value is displayed on the LCD.
PressthePRINTbuttontoprintthefollowing:
• 1setofmeasurements(V/R/DAR /PI/DD/date/time)fornormaltests.
• TheR(t)valuesifthe“time-controlledtest”hasbeenused.
To stop printing,movethepositionoftheselectorswitch.
Depending on the function used, the following models are obtained:
Insulation Measurement
AEMC
®
InstrumentsModel5060
Instrumentnumber:000001
INSULATIONRESISTANCETEST
OBJECT:01 ..................................... TEST:01(only printed in MR mode)
Description:....................................................
........................................................................
Date: ............................................03.31.2001
Starttime: ............................................14:55
Testduration: ......................... 15min.30sec
Temperature: ..............................°C.........°F
Relativehumidity: ...................................... %
Testvoltage: ....................................... 1000V
Insulationresistance(R): ...............385GOhm
DAR(R1’/R30”): .................................1.234
PI(R10’/R1”):......................................2.345
Comments: ....................................................
........................................................................
Dateofnexttest: ............................../..../.......
After a ‘time-controlled test’ other results are printed (interval samples):
 Time Resistance Voltage
00:30 35.94GOhm 1005V
01:00 42.00GOhm 1005V
01:30 43.50GOhm 1005V
etc...
A space for the operator’s signature is available at the end of the printout.
