ThefollowingtabledenesthebuttonsthatarefunctionalwheninSET-UP,andthe
correspondingdisplaywiththepossiblerangeofadjustment.
Parameter program Command Button
Display
main small symbol value
Duration of
“time-controlled test”
tESt 30:00 min. sec 1:00 - 59:59
1st and 2nd times for
PI calculation
R-DAR-PI-DD
second time
(10:00)
first time
(1:00)
min : sec :30 - 59:59
Time between interval
samples in
“time-controlled test”
R(t) 00:30 min : sec 0:05 - 30:00
Limit for 500V - 2TΩ ALARM 500k
Ω 500V ALARM <
30k-2TΩ
and >/<
Limit for 1000V - 4TΩ
ALARM
(2nd press)
1M Ω 1000V ALARM <
100k-4TΩ
and > / <
Limit for 2500V - 10TΩ
ALARM
(3rd press)
2.5M Ω 2500V ALARM <
300k - 10TΩ
and > / <
Limit for 5000V - 10TΩ
ALARM
(4th press)
5M Ω 5000V ALARM <
300k - 10TΩ
and > / <
Limit for Var - 50/5000V
ALARM
(5th press)
5M Ω Set ALARM <
10k - 10TΩ
and > / <
Time V/TIME 12 :55
hh (00-23)
mn (00-59)
Date (European version) V/TIME
(2nd press) 17.03 2000 dd.mm.yyyy
Version : USA, European V/TIME (3rd press) USA/Euro USA/Euro
Clear Memory MEM
then MEM (2s) cLr ALL MEM
Selective clearing
of memory
MEM then
and
and MEM (2s)
FrEE/OCC
OBJ : TEST
number
MEM 00...99
Baud PRINT 9600 bAUd 300...9600
Buzzer
On
ON / OFF
Auto switch-off
(2nd press)
On ON / OFF
Default configuration
(3rd press)
then START
DFLt SEt
User selectable test
voltage
(4th press)
SEt 100V V 40 / 5100V
Disturbance limit voltage
(5th press)
0.03 V dISt V 0.03/0.10/0.20
Automatic range
(6th press)
Auto rAnG Auto/1/2/3
Test voltage locking
(7th press)
oFF 1000V
ON / OFF
40-5100V
The values shown on this table, in the “Display/main” and “Display/small” columns, are the factory default values. In
case they are accidentally changed, it is possible to get them back. (see § 2.5.10).
