18
Micro-Ohmmeter Model 6250
7. Activate temperature compensation by pressing the button.
The reference temperature will appear followed by the ambient
temperature on the top line of the display.
8. Start the test by pressing the START/STOP button. The resistance
reading will appear on the lower line of the display. The symbol
OPER will appear on the lower left to indicate that a test is in
process. The Stand-by symbol STBY will appear when the test is
completed. Resistive element tests will stop automatically. Inductive
and AUTO testing will stop when the operator pushes the START/
STOP button a second time.
9. Store the test result in memory by pressing the MEM button at the
conclusion of a test. The next available location will be presented on
the top line of the display. To use this location, press the MEM button
a second time.
10.
Recall readings from memory by pressing the yellow button fol-
lowed by the MEM button. The last measurement stored in location
OBJ: X TEST: X will be displayed. Use the ▲, ▼ and ► buttons to
select the object and test memory location to review. All information
from the measurement is available for review including metal type,
ambient and reference temperatures, resistance at ambient and refer-
ence temperatures, test range and test current.
Typical Operational Display
