Micro-Ohmmeter Model 6250
41
5.2
Displaying and Printing Stored Measurements
NOTE: To display or print a measurement result stored in memory, press
the yellow button followed by the MR button.
The measurement value for the last object and test saved is displayed.
Example: Object 1 and Test 3 are displayed.
01:03.
OBJ : TEST
The test unit number will be blinking. In this example the 3 will be blinking.
Change the object and test numbers using the arrow buttons. As you
change memory locations, the stored measurement value will be dis-
played. The following measurement components are also accessible if
stored.
The selected memory location will display:
• The number of the object and test that correspond to the memory
location
• The active range and current level during the measurement
• The measurement value with any compensation used
• The alarm icon for any active alarms that occurred during the
measurement
The parameters set for the alarm threshold, reference temperature,
ambient temperature and metal correction coecient are not directly
accessible. They are accessible by pressing the following:
• Press the button to display ambient temperature at the time
of the stored measurement.
• Press the button a second time to display the reference tem-
perature that the measurement was compensated to.
• Press the button to display the type of metal and alpha
value used for compensation at the time of the measurement.
• Press the PRINT button to print the measurement results stored at
the current memory location. An optional serial printer is required
for this feature.
