42
Micro-Ohmmeter Model 6250
NOTE: Only memory locations with stored measurements are accessible.
Measurement data stored in memory can be accessed directly from any
switch position except OFF and SET-UP for printing.
Press the yellow button followed by the PRINT MEM button
to access measurement results stored in memory for printing. An
optional serial printer is required for this feature. Use the arrow
buttons to select the object and test to be printed.
A typical printed report using the optional DPU-414-30B portable battery
operated printer (Cat. #2140.21) is shown below.
CHAUVIN ARNOUX - CA6250
NUMBER : ...................................
OBJECT: TEST:
DESCRIPTION: ...............................
............................................
............................................
Meas. Date : ___/___/___
Meas. Type : LOW INDUCTIVE
Metal Type : Cu
Coeff. Metal : 3.93
Measurement Temperature : 23.2 C
Reference Temperature : 20.0 C
Resistance Value (T
amb
) : 1294.6 Ohm
Resistance Value (T
ref
) : 1287.2 Ohm
COMMENTS : ...............................
............................................
............................................
Next test date : ___/___/___
Figure 5-1
Enclosed with this manual is a pad containing 50 forms to record the measurement
results manually. They may be photocopied as needed or downloaded from our
website at www.aemc.com/techinfo/index.asp located in the Micro-ohmmeter
section.
