Micro-Ohmmeter Model 6250 19
4.2 Instrument Configuration (SET-UP Mode)
4.2.1 Program Menu Tree
The menu tree below shows the order in which functions appear in the
Menu and sub-menus of the set up mode.
Set
r5 – OFF – Trig – PC – uT100 – Print
buzz – off – low high
EdSn – displays internal serial number
EdPP – displays firmware number
Lang – Lg Gb – Lg F
trEF – value
tAnb – Prb – nPrb
nEtA – Copper alpha – Aluminum alpha, Other Metal
ALPH – value
dEg – dEgF – dEgC
ALAr – Alarm 1 – Alarm 2
LlgH – t=OFF – t=1 – t=5 – t=10
nEn – dEL – dEL O – Y – n
The cursor buttons ▲, ▼ and ► have the following functions in the
SET-UP menu:
• The up Arrow ▲ button selects the next function to be programmed
in the top level menu and increments the value of the ashing
variable in the sub-menus.
• The down Arrow ▼ button selects the previous function to be pro-
grammed in the top level menu and decrements the value of the
ashing variable in the sub-menus.
• The right arrow ► button selects the function displayed in the top
level menu and moves the cursor one place to the right or validates
the programming in the sub-menus. See Cables and Printer Used
with the Interface Port (§5.3) for proper connections.
