AERMEC SWP200 - User Branch (UTT) Table of Parameters; User Branch Diagram (UTT)

53
SWP_5287500_00
12.2. USER BRANCH (UTT) TABLE OF
PARAMETERS
PARAMETER DEFAULT LIMITS UNIT DESCRIPTION
U01 60,0 H02-H01 °C Boiler water set point (Automatic
operation)
U02 60,0 H02-H27 °C Boiler water set point (Manual
operation)
12.3. USER BRANCH DIAGRAM (UTT)
Boiler water set point
(Automatic operation)
Boiler water set point (Manual
operation)
Uo1 value
variation
Uo2 value
variation
