3.4
Moisture
page
Fig.
9
(1)
Bale
moisture
(2)
Alarm
limit
(3)
Moisture
value
offset
(4)
Dye
marker
ON
(5)
Dye
marker
threshold
(6)
Dye
marker
prime
(7)
Sensor
ON
(symbol
shows)
Fig.
10
(1)
Bale
moisture
(2)
Alarm
limit
(3)
Moisture
value
offset
(4)
Bale
width
setting
(5)
Crop
type
(6)
Air
calibration
button
(7)
Sensor
ON
(symbol
shows)
(8)
Software
version
for
the
moisture
sensor
3
Operation
SimplEbale
35
34
36
