5.3.6 Lamp diagnostics
Step Diagnostic Result Action
1 Do the status lamp
indicators on the
diagnostic screen
illuminate when lamps are
set to ON?
Yes Go to step 2.
No Go to step 3.
2 Are the keypad status
indicator lamps on?
Yes Go to step 3.
No See CAN diagnostics.
3 Does the fuse for the lamp
operate correctly?
Yes Go to step 4.
No Replace the fuse.
4 Does the relay for the
service lamp and the relay
for the field lamp operate
correctly?
Yes Go to step 5.
No Replace the relay.
5 Is there damage to the
harness?
Yes Replace the harness.
No Go to step 6.
6 Do a check of the
connectors. Is there a 12
V supply to the
connectors?
Yes Refer to your approved
dealer.
No Repair or replace the
lamps.
5.3.7 Automatic lubrication system diagnostics
Step Diagnostic Result Action
1 Is the automatic
lubrication enabled on the
Baler Options on the
terminal?
Yes Go to step 2.
No Activate the automatic
lubrication function on the
Baler Options on the
terminal.
2 Can the PTO speed be
identified?
Yes Go to step 3.
No See PTO Speed
Diagnostics.
